AOC LE40A1330/64 User Manual

53
8.4 IR Board
715G5471R02000004S
U201
IRM-H638M3/TR2
GND
1
GND
2
OUT
3
VCC
4
IR
033G8032 5F HR
C201
0.1uF 50V
VCC
R201 15K 1/10W
081G 14 24 EL
OEM MOD EL Size
Rev
Date
Sheet of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
A
A
22Wednesday , February 01, 2012
<
称爹 >
02-IR&LED
R203 220 OHM 1/10W
LED_B
CN201
CONN
1
2
3
4
5
67
LED_R
RED
BLUE
LED201
LED
1
23
4
R202 220 OHM 1/10W
Dip LED
Top Vie w
IR
16 mm
37mm
