55
Item Description
1 BEZEL
2 PANEL
3 DECO_BEZEL
4 DECO_BEZEL
6 IR BOARD
8 CABLE TIE
9 SPEAKER
10 STAND
11 BKT_STAND
13 INSULATING SHEET
14 ADAPTER BOARD
17 BOLT
Item Part No. Description
18 MAIN BOARD 5 0M1G1030 6 47 CR3 SCREW(DECO_BEZEL/PANEL)
20 BKT_IO 12 0Q1G 940 8 47 CR3 SCREW(BKT STAND/STAND)
21 BKT_IO 15 0M1G1730 6120 SCREW(POWER BOARD/PANEL)
25 BKT_HINGE 27 0Q1G1030 6120 SCREW(BKT HINGE/COVER STAND)
26 COVER_STAND 30 0Q1G 130 6120 SCREW(BKT BASE/BASE)
28 BASE 31 0M1G1740 10225 CR3 SCREW(BASE/BTK BTM/STAND COVER)
29 BKT_BASE 33 0M1G1740 10225 CR3 SCREW(BKT STAND/BTK HINGE)
32 FOOT PAD 37 0M1G1030 6 47 CR3 SCREW(REAR COVER/PANEL)
34 DECO_KEY 38 0Q1G 940 8 47 CR3 SCREW(REAR COVER/DECO BEZEL)
35 KEY BOARD 39 0Q1G 940 8 47 CR3 SCREW(REAR COVER/DECO BEZEL/STAND)
36 REAR_COVER 40 0M1G1030 6 47 CR3 SCREW(REAR COVER/AC SOCKET)
