24
Specification
General Specification
Panel
Model name Q27B2S2
Driving system TFT Color LCD
Viewable Image Size 68.5cm diagonal
Pixel pitch 0.2331(H)mm x 0.2331(V) mm
Display Color 16.7M Colors
Others
Horizontal scan range 30k-150kHz
Horizontal scan Size(Maximum) 596.736mm
Vertical scan range 48-100Hz
Vertical Scan Size(Maximum) 335.664mm
Optimal preset resolution 2560x1440@60Hz
Max resolution 2560x1440@100Hz
Plug & Play
VESA DDC2B/CI
Power Source 19Vdc, 2.0A
Power Consumption
Typical(default brightness and contrast) 30W
Max. (brightness = 100, contrast =100) ≤ 45W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type HDMI/DP/Earphone
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°C~ 40°C
Non-Operating -25°C~ 55°C
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0 ~ 5000 m (0~ 16404ft )
Non-Operating 0 ~ 12192m (0~ 40000ft )
