3.3 Compatible Mode Table
T942We
Resolution
Pixel Rate
( MHz )
Horizontal
( KHz )
Vertical
( Hz )
V_Total
( Line )
Polarity
( H / V )
DOS 640x350/70 25.18 31.47 70.09 449 p / n
DOS 720x400/70 28.32 31.47 70.09 449 n / p
DMT 4:3 640x480/60 25.18 31.47 59.94 525 n / n
MAC 640x480/67 30.24 35.00 66.67 525 n / n
DMT 4:3 640x480/72 31.50 37.86 72.81 520 n / n
DMT 4:3 640x480/75 31.50 37.50 75.00 500 n / n
DMT 4:3 640x480/85 36.00 43.27 85.01 509 n / n
DMT 4:3 800x600/56 36.00 35.16 56.25 625 p / p
DMT 4:3 800x600/60 40.00 37.88 60.32 628 p / p
DMT 4:3 800x600/72 50.00 48.08 72.19 666 p / p
DMT 4:3 800x600/75 49.50 46.88 75.00 625 p / p
DMT 4:3 800x600/85 56.25 53.67 85.06 631 p / p
MAC 832x624/75 57.28 47.73 74.55 667 n / n
WVGA 1024X600/60
DMT 4:3 1024x768/60 65.00 48.36 60.00 806 n / n
DMT 4:3 1024x768/70 75.00 56.48 70.07 806 n / n
DMT 4:3 1024x768/75 78.75 60.02 75.03 800 p / p
IBM 1024x768/76 83.10 61.10 76.00 803 p / p
DMT 1024x768/85 94.50 68.68 85.00 808 p / p
1152x864/60 79.90 54.00 60.00 900 p / p
1152x864/70 94.50 63.90 70.00 912 p / p
DMT 1152x864/75 108.00 67.50 75.00 900 p / p
MAC 1152x870/75 100.00 68.68 75.06 915 n / n
SUN 1152x900/66 92.94 61.80 65.95 937 p / p
SUN 1152x900/76 105.56 71.71 76.05 943 p / p
CVT 16:9 1280x720/60 74.50 44.77 59.86 748 n / p
CVT 16:9 1280x720/75 95.75 56.46 74.78 755 n / p
CVT 16:9 1280x720/85 110.25 64.40 84.85 759 n / p
CVT 15:9 1280x768/60 79.50 47.78 59.87 798 n / p
CVT 15:9 1280x768/75 102.25 60.29 74.89 805 n / p
CVT 15:9 1280x768/85 117.50 68.63 84.84 809 n / p
CVT 1280x800/60 83.50 49.70 59.81 831 n / p
CVT 1280x800/75 106.50 62.80 74.93 838 n / p
CVT 1280x800/85 122.50 71.55 84.88 843 n / p
DMT 4:3 1280x960/60 108.00 60.00 60.00 1000 p / p
CVT 4:3 1280x960/75 130.00 75.23 74.86 1005 n / p
DMT 4:3 1280x960/85 148.50 85.94 85.00 1011 p / p
DMT 5:4 1280x1024/60 108.00 63.89 60.02 1066 p / p
SUN 5:4 1280x1024/66 117.00 71.70 67.00 1067 p / p
DOS 5:4 1280x1024/72 130.22 76.00 72.00 1064 p / p
DMT 5:4 1280x1024/75 135.00 79.98 75.03 1066 p / p
SUN 5:4 1280x1024/76 138.01 81.10 76.00 1066 n / n
DMT 5:4 1280x1024/85 157.50 91.15 85.02 1072 p / p
DMT 16:9 1360x768/60 85.50 47.71 60.02 795 p / p
