AOC T2442e - Page 49

49
PANEL_ON
VCC3
TPS54286PWPR
U7408
5V_POWER
1084_33
U707
VCC5
AO4449
Q706
VCC18_CORE
V33ADC / VCCADC / VDDA33
HX6201
U405
AVDD18 / VCCLV
HX6202A
U405
VCC3
MX25L4005AM2C
U402
VCC18_PLL
V33_AUD
V33_ADC
V18AUD / PVDD_LV
HX6201
U405
V33AUD
HX6201
U405
V18AUD / PVDD_LV
V33AUD
V33HDMI / VCCADC / VDDA33
AVDD18 / VCCLV
PANEL
PANEL_VCCAO4449
Q406
VCC5 AP2176
U604
EARPHONE AMP
16V_POWER_AP
R2A15112FP
U603
V18_33HDMI
HX6201
U405
VCC18
AP1117D18
U703
200mA
1180mA
117mA
16mA
39mA
281mA
16V_POWER
POWER_ON
VCC3AD
VCC3IO
/ V33LV
VCC3AD
VCC3IO / V33LV
HX6201
U405
VCC5
M24C02-
U101
M24C02
U301
M24C32
U404
