AOC T2442e - Page 77

77
T942We/ T2442e
Item Description
1 DECO
2 BEZEL
3 LENS
4 LENS_IR
5 INSULATE SHEET
6 MAIN FRAME
8 MYLAR
10 COVER_RCA
Item Part No. Description Qty
11 KENSINGTON-BKT S1 0M1G 330 6120 SCREW(BASE/DIE-CASTING) 4
12 BKT-VESA S2 0M1G 330 8120 SCREW(HINGE/STAND) 2
13 REAR COVER S3 0M1G 930 8 47 CR3 SCREW(REAR COVER/HDMI) 2
14 HINGE S4 0M1G1030 6120 SCREW(POWER BOARD/MAIN FRAME/MAIN BOARD) 8
15 STAND S5 0M1G1040 6120 SCREW(POWER BOARD/AC) 1
16 BASE S7 0M1G1740 10120 SCREW(REAR COVER/HINGE) 4
17 PLATE S9 0Q1G 130 6120 SCREW(BASE/PLATE) 3
18 DIE-CASTING S10 0Q1G 930 8 47 CR3 SCREW(REAR COVER/BEZEL) 6
19 COVER HINGE S12 Q01G6139 1 SCREW(BASE/DIE-CASTING) 1
20 FOOT PAD S13 0Q1G1040 8120 SCREW(SPEAKER/BEZEL/MAIN FRAME) 8
