Assembly
Step5:Fix netting and curtain hanging tubes(D) on crossbar (C)with M6x72mm bolts (Z),nuts(1)and
plastic washers(3).
Repeat this step for the remaining crossbar
Note:this crossbars is for size12ft
Step6:Fix netting and cur tain hanging tubes(D1) on crossbar(C1) with M6x72mm bolts (Z),nuts(1) and
plastic washers(3).
Repeat this step for the remaining crossbar
Note:this crossbars is for size10ft
