AOODOR 800-034 - Page 9

Assembly
Step10:Insert the top roof poles(J),(K) into top connector(R) as figure
Inser (L)into (K),and fix air vent pole with top connector pole(E) using M6x28mm bolts(Y) and nut(1)
R
J
J
K
L
C
C1
K
K
L
Y
1
J
9
10
10ft
12ft
E
L
