Aopos Anypos200 - Setup and Operation; Attaching Customer Displays

Anypos Point of Service
DESCRIPTION
1 AC adapter connector
2 PS2 keyboard port
3 PS2 mouse port
4 Parallel port (LPT1)
5 VGA port
6 USB 1&2&3&4
7 10/100 NIC port
8 Microphone
9 Line-out
10 DC +12V Output
OUT 12V
11 COM1 port
COM1
12 COM2 port
COM2
13 COM3 port
COM3
14 COM4 port
COM4
Attaching VFD Customer Display
1、Connect the customer
display through the
cable to customer
display port on the
bottom panel.
4
