AOX AOX-Q-015 User Manual

- 2 -
1. General Safety Instructions
Do not open the upper shell when with main power
Check the specification on the nameplate is the same as order specification.
Pls reading the instruction book before using
Pls reset the limit switches when mounting the valve
Do not change the internal wiring
If the power supply is 3 phase, should to check the rotating direction.
2. Summary
"AOX-Q" series electric actuator is used for controlling 0° ～ 270° rotation of the valves and other similar
products, such as butterfly valve, ball valve, damper, flapper valve, cock valve etc. It widely applies to petroleum,
chemical, water treatment, shipping, paper making, power plant, heating, light industry and other industries.
Drived by 380V/220V/110VAC power or 24V/110VDC power, inputs 4-20mA or 0-10VDC control signal,
moves valve to the right position, and achieves to automatic control, maximum output torque is 6000N·M.
3. Performance Features
3. 1. Shell--The shell is made of aluminum alloy, with anodic oxidation treatment and polyester powder coating.
It is strong corrosion-resistant and enclosure IP67,NEMA 4 and 6, IP68 and explosion-proof is optional.
