APC AP9617 Quick Start

Quick Start: Network Management Card – DC Series
Contents
Quick Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview 1
TCP/IP configuration methods 1
APC Management Card Wizard 2
BOOTP configuration 3
Local access to the control console 4
Remote access to the control console 6
Control console 7
How to Access a Configured Network Management Card . . 8
Overview 8
Web interface 8
Telnet 8
SNMP 8
FTP 9
APC Management Card Wizard 9
How to Recover from a Lost Password . . . . . . . . . . . . . . . 10

APC AP9617 Specifications

General

Type	Network Management Card
Model	AP9617
Data Link Protocol	Ethernet, Fast Ethernet
Network Ports Qty	1
Network Protocols	TCP/IP, HTTP, HTTPS, SNMP, Telnet, SSH
Management	SNMP
Compatibility	Smart-UPS
Remote Management Protocol	SNMP, HTTP, HTTPS, Telnet, SSH
Security	SSL, SSH
Operating Temperature	0 to 45 °C
Storage Temperature	-15 to 65 °C
Humidity	0 to 95% non-condensing
Ports	RJ-45 Ethernet
