24 InRow™ Chilled Water Air Conditioners Technical Specifications 990-4618A-001
Note: All values are accurate to ± 0.73 kW (2500 BTU/hr) and based on full speed with standard filters.
Note: Any CW flow rate of 3.9 GPM-5.0 GPM may have increased error in Flow Rate and Power Calculation. A Fluid Flow
Fault may result. Any flow rate under 3.0 GPM may also display as 0 in Flow Rate and Power Calculation.
Note: For ACRC500/ACRP500 series, reduce airflow and cooling capacity specifications by 7% for cooling units run at low
input voltage (380V).
35.0°C DB, 19.8°C WB (95°F DB, 67.7°F WB)
5.5°C (10°F) ACRC100 28.4 (97000) 28.4 (97000) 1.00 1.27 (20.1) 111.83 (37.4)
6.6°C (12°F) ACRC100 26.9 (92000) 26.9 (92000) 1.00 1.01 (16.0) 72.78 (24.5)
7.7°C (14°F)
ACRC100 26.4 (90000) 26.4 (90000) 1.00 0.85 (13.4) 52.42 (17.6)
ACRC500/ACRP500 62.0 (212000) 60.2 (205000) 0.97 1.9 (30.6) 90 (30.3)
8.8°C (16°F)
ACRC100 25.5 (87000) 25.5 (87000) 1.00 0.72 (11.3) 38.09 (12.7)
ACRC500/ACRP500 58.8 (201000) 57.0 (195000) 0.97 1.6 (25.4) 63 (21.3)
10°C (18°F)
ACRC100 24.6 (84000) 24.6 (84000) 1.00 0.62 (9.8) 29.2 (9.7)
ACRC500/ACRP500 55.6 (190000) 53.9 (184000) 0.97 1.4 (21.4) 45 (15.2)
11.1°C (20°F)
ACRC100 24.3 (83000) 24.3 (83000) 1.00 0.55 (8.7) 23.44 (7.9)
ACRC500/ACRP500 52.4 (179000) 50.9 (174000) 0.97 1.2 (18.3) 33 (11.1)
37.8°C DB, 20.7°C WB (100°F DB, 69.2°F WB)
6.6°C (12°F) ACRC100 30.5 (104000) 30.5 (104000) 1.00 1.14 (18.0) 90.89 (30.5)
7.7°C (14°F) ACRC100 30.2 (103000) 30.2 (103000) 1.00 0.97 (15.3) 66.73 (22.4)
8.8°C (16°F)
ACRC100 29.3 (100000) 29.3 (100000) 1.00 0.82 (12.9) 49.01 (16.4)
ACRC500/ACRP500 66.4 (227000) 65.0 (222000) 0.98 1.8 (28.6) 79 (26.6)
10°C (18°F)
ACRC100 28.7 (98000) 28.7 (98000) 1.00 0.72 (11.3) 38.23 (12.7)
ACRC500/ACRP500 63.1 (215000) 61.8 (211000) 0.98 1.5 (24.2) 57 (19.2)
11.1°C (20°F)
ACRC100 28.7 (98000) 28.7 (98000) 1.00 0.64 (10.1) 31.21 (10.4)
ACRC500/ACRP500 59.8 (204000) 58.7 (200000) 0.98 1.3 (20.7) 42 (14.3)
40.6°C DB, 21.6°C WB (105°F DB, 70.8°F WB)
6.6°C (12°F) ACRC100 34.0 (116000) 34.0 (116000) 1.00 1.27 (20.0) 111.13 (37.2)
7.7°C (14°F) ACRC100 33.7 (115000) 33.7 (115000) 1.00 1.07 (16.9) 80.99 (27.3)
8.8°C (16°F)
ACRC100 33.1 (113000) 33.1 (113000) 1.00 0.92 (14.6) 61.36 (20.6)
ACRC500/ACRP500 74.8 (256000) 73.3 (250000) 0.98 2.0 (32.1) 99 (33.3)
10°C (18°F)
ACRC100 32.8 (112000) 32.8 (112000) 1.00 0.81 (12.9) 48.39 (16.17)
ACRC500/ACRP500 71.4 (244000) 70.0 (239000) 0.98 1.7 (27.3) 72 (24.3)
11.1°C (20°F)
ACRC100 32.5 (111000) 32.5 (111000) 1.00 0.72 (11.4) 38.77 (12.9)
ACRC500/ACRP500 68.1 (233000) 66.7 (228000) 0.98 1.5 (23.4) 54 (18.02)
Temperature DB,
WB
°C (°F)
CW
Delta T
°C (°F)
Model Series
Total Net Capacity
Sensible Net
Capacity
Sensible
Heat Ratio
CW
Flow Rate
Total CW
Pressure Drop
kW (BTU/hr) kW (BTU/hr) SHR l/s (GPM) kPa (ft H2O)
