APC Network Management Card AP9617 User Manual

Expansion/Triple Chassis Installation
Overview
Use an Expansion Chassis or a Triple Expansion Chassis if the
UPS has no card slot available.
The Management Card installs in the chassis and
communicates with the
UPS
through the cable connection
between the chassis and the
UPS
.
When to use the
AC
adapter
(AP9505)
Use the optional
AC
adapter with a chassis under the following
circumstances:
• To connect the chassis to an independent AC input so
that the Management Card can continue to operate if the
UPS
is turned off or fails.
• To provide the
APC
management products mounted in a
Triple Expansion Chassis with more current than the
UPS
can provide through the
UPS
-to-chassis cable.
– A Silcon UPS provides up to 500 mA.
– A Matrix-UPS, Smart-UPS, or Symmetra provides up
to 200 mA.
For information about the current requirements for
APC
management products, do the following:
a. Go to APC’s Support page
b. Click the Knowledge Base link in the “Search the
Knowledge Base” section.
c. Use “current draw” as your search phrase.
d. Select the “Recommended connection order and
power requirements for APC SmartSlot accessories”
document.
Step 1:
Disconnect the
chassis from all
power
Make sure that the chassis is disconnected from any power
source: Disconnect the chassis cable from the
UPS
and, if the
UPS uses an
AC
adapter, disconnect that adapter from the
chassis.
Note
Use only a Silcon Triple Expansion Chassis
(AP9604S) with a Silcon UPS.
