APDM Opal V2R - Logging Modes Explained

To Next Page

To Previous Page

Synchronized Logging Mode

In the synchronized logging mode, multiple sensors can be wirelessly synchronized with each other. Each sensor’s data

will be recorded to the on-board ash memory.

To Start Recording

Undock the sensors after conguration. After a few seconds, they will start recording to their ash memory. When

within wireless contact with each other, they will synchronize their clocks. To start an additional recording in a

separate le, connect and disconnect the sensors from their cables or Docking Stations. No re-conguration is

necessary.

To Import Recorded Data

Dock the sensor(s). Click on the “Convert” button in the toolbar. You can specify regions of the logged data to

convert to HDF format (identical to the streamed data format) based on time ranges or button events.

Low Power Logging Mode

In the low power logging mode, each sensor’s radio is turned o to save power. The sensors will be synchronized at

the start of recording, but they will not be actively synchronized while logging and some level of clock drift will occur

during long recordings.

To Start Recording

Undock the sensors after conguration. The sensors will stop recording once they are docked again.

To Import Recorded Data

Dock the sensor(s). Click on the “Convert” button in the toolbar.
