Table A-2: Guidance and Manufacturer’s Declaration - Electromagnetic Immunity

The Opal System is intended for use in the electromagnetic environment specied below. The customer or user of the

Opal System should assure that it is used in such an environment.

Immunity Test IEC 60601 Test Level Compliance Electromagnetic Environment - Guidance

Electrostatic + 8 kV contact + 8 kV contact Floors should be wood, concrete, or ceramic tile. If oors are

Discharge + 15 kV air + 15 kV air covered with synthetic material, the relative humidity should be at

(ESD) least 30%.

IEC 61000-4-2

Electrical Fast + 2kV for power + 2kV for power The mains power quality should be that of a typical commercial or

Transients and supply lines supply lines hospital environment.

Bursts (EFT)

IEC 61000-4-4

Surge + 2kV dierential + 2kV dierential The mains power quality should be that of a typical commercial or

IEC 61000-4-5 mode mode hospital environment.

+ 2 kV common + 2 kV common

mode mode

Voltage Dips 100% dip in 0.5 100% dip in 0.5 The mains power quality should be that of a typical commercial or

and cycles cycles hospital environment. If the user of the Opal System

Interruptions 60% dip in 5 cycles 60% dip in 5 cycles requires continued operation during a power mains interruption, it

IEC 61000-4-11 30% dip in 25/30 30% dip in 25/30 is recommended that the Opal System be powered from an

cycles cycles uninterruptible power supply or battery.

100% dip in 100% dip in

250/300 cycles 250/300 cycles

Magnetic Field 30 A/m 30 A/m Power frequency magnetic elds should be at levels characteristic

Immunity of a typical location a typical commercial or hospital environment.

(50/60 Hz)

IEC 61000-4-8
