Aphex CHANNEL - General Specifications; Microphone and Output Specs; Dynamics and Tone Control Specs; Digital Audio and Power Specs

Page 12
OUTPUT
Connector:
Type:
Output Z Balanced:
Output Z Unbalanced:
Nominal Level
Maximum Output Level (MOL):
5.1 GENERAL SPECIFICATIONS
XLR-3M and TRS 1/4” phone jack
XLR is Impedance Balanced (may be used unbalanced); TRS is unbalanced.
XLR: 66Ω
XLR: 33Ω − TRS: 600Ω
XLR: +4dBu; TRS: -10dBV
XLR: +25dBu Unloaded; TRS: +11dBV
5.0 Specifications
All specifications are subject to change without notice.
MIC INPUT Connector:
Type:
Input Z:
Instrument Connector:
Instrument Input Z:
Type:
Maximum Input Level (MIL):
CMRR:
Nominal Preamp Gain:
Phantom Power:
Pad:
EIN:
XLR-3F
Transformerless, NPN active balanced, tube second stage
2KΩ nominal
1/4” TS
10MΩ nominal
Transformerless, NPN active balanced, tube second stage
0dBu
Greater than 70dB @ 60Hz
20 to 65dB
+48VDC
20dB
-127dBu (Input Shorted)
COMPRESSOR
Attack/Release:
Ratio:
Threshold:
Knee:
Program dependent, user variable release baseline.
4:1
Fixed
Medium Hard
INSERT
Connector Type Send:
Connector Type Return:
Nominal Operating Level:
Point of Insertion:
1/4” TRS Phone Jack, Balanced
1/4” TRS Phone Jack, Balanced
0dBu
Between dynamics processing and equalizers.
GATE
Attack:
Hold/Release:
Threshold:
Depth:
0.1 millisecond
300 milliseconds/400 milliseconds
Variable -50 to +20dB
Variable, 1 to 58dB
DE-ESSER
Attack:
Release:
Threshold:
Raio:
Active Band:
0.1 millisecond
100 milliseconds
Variable -20 to +20dB
5:1
4.KHz to 20KHz Linkwitz-Riley 24dB/octave crossover
BIG BOTTOM
Frequency Tune:
MIx:
50Hz to 280Hz
OFF to +12dB
PARAMETRIC EQ
Frequency Tune:
Peak/Dip:
Q Range:
240Hz to 8KHz
+/- 12dB
0.5 to 5
AURAL EXCITER
Frequency Tune:
Mix:
500Hz to 5KHz
OFF to +12dB
ANALOG AUDIO
THD:
IMD:
Freq Resp (FLAT):
<.01% @ +4dBu Out
<.01% @ +4dBu Out
18Hz to 24KHz +/- 1dB
DIGITAL AUDIO
Internal Sample Rates:
External Sample Rates:
Resolution:
Word Clock Input:
Word Clock Output:
Dynamic Range:
Noise Dither:
Level Equivalency:
44.1KHz, 48KHz, 88.2KHz, 96KHz
Automatically syncs to any word clock between 32KHz and 96KHz
24 Bits
BNC Jack, High Z, Captures <1Vp-p to 5Vp-p
BNC Jack, 75 Ohms, 5Vp-p
Digital dynamic range greater than analog front end.
Dithered by analog preamp noise floor. Equivalent to 16-bit digital audio dither.
-20dBFS Digital = +4dBu Analog
OTHER SPECS
Power requirements:
Power Consumption (maximum):
Dimensions:
Depth Behind Front Panel:
Net Weight:
Shipping Weight:
Tube Type:
85 to 260V~, 50-60Hz
12 Watts
19” W x 1.75” H x 8.25” overall depth (482.6mm W x 445mm H x 209.6mm overall depth)
7.5” (190.5mm)
Rack-mounted: 6lbs. (2.73kg)
9lbs. (4.1kg)
12AT7/ECC81 Dual Triode
Aphex Channel
