AC VOLTAGE SELECTOR
Switch between 90-120 and 200-250VAC
SWITCH IT ONLY WHEN THE POWER IS OFF
FUSE HOLDER
REPLACE WITH A TYPE
0.5A slow-blow for 90-125 VAC
0.25A slow-blow for 200-250 VAC
AC INLET
CHECK VOLTAGE
SELECTOR BEFORE
TURNING 2500 ON
XLR INPUT
+4dBu
Pin 2 HOT
XLR OUTPUT
+4 dBu
Pin 2 HOT
SIDE CHAIN
INPUT , +4dBu
Normals to
XLR INPUT
