E X P A N S I O N B U S C O N N E C T O R :
T h i s c o n n e c t o r i s t h e s u m m i n g i n p u t s / o u t p u t f o r t h e 8 2 0 0 . I t p l u g s i n t o t h e 7 8 0 0 a n d t o
7 6 0 0 s .
E X P A N S I O N C O N N E C T O R
A u t o m a t e d P r o c e s s e s , I n c .
E X P A N S I O N B U S
P A G E 4
8 2 0 0 B U S C O N N E C T O R P I N O U T
S T E R E O L E F T - 8 .
S T E R E O R I G H T - 1 2 .
B U S 2 - 2 0 .
B U S 1 - 1 6 .
B U S 4 - 2 8 .
B U S 3 - 2 4 .
S E N D 1 - 3 2 .
S E N D 3 - 4 0 .
S E N D 2 - 3 6 .
S E N D 4 - 4 4 .
G N D 4 6 .
S O L O A U D I O R I G H T - 5 2 .
S O L O A U D I O L E F T - 4 8 .
G N D 5 6 .
G N D 5 4 .
G N D 6 0 .
G N D 5 8 .
G N D 3 0 .
G N D 1 0 .
7 . S T E R E O L E F T +
1 1 . S T E R E O R I G H T +
1 5 . B U S 1 +
1 9 . B U S 2 +
2 3 . B U S 3 +
2 7 . B U S 4 +
3 1 . S E N D 1 +
3 5 . S E N D 2 +
3 9 . S E N D 3 +
4 3 . S E N D 4 +
4 5 . G N D
4 7 . S O L O A U D I O L E F T +
5 1 . S O L O A U D I O R I G H T +
5 3 . G N D
5 5 . G N D
5 7 . G N D
5 9 . G N D
2 9 . G N D
9 . G N D
4 1 . G N D G N D 4 2 .
3 7 . G N D G N D 3 8 .
3 3 . G N D G N D 3 4 .
G N D 5 0 .4 9 . G N D
G N D 2 6 .2 5 . G N D
2 1 . G N D G N D 2 2 .
1 7 . G N D G N D 1 8 .
G N D 1 4 .1 3 . G N D
G N D 6 .5 . G N D
G N D 4 .3 . G N D
G N D 2 .1 . G N D
M U T E G R O U P B U S 6 2 .6 1 . C O M P R E S S O R D C L I N K
S O L O D C B U S 6 4 .6 3 . S O L O I N P L A C E B U S
T h i s i s P i n 1 . S m a l l a r r o w
o n t o p o f c o n n e c t o r
i n d i c a t e s P i n 1 P o s i t i o n .
P i n 6 3
