Aplus PlusIII-6KLRB - 5. Operation and Status Display; 5.2 Operating Modes Overview

5.2 Operating Mode
The different graphic symbol could be displayed corresponding to current operating
mode or status.
5.2.1 Line mode
The example of LCD display in Line mode is shown in the following diagram.
The symbol of operating in Line mode
Fig. 5-3 Line mode
Input
Output
220 V
273.0 V
220 V
60 Hz
60 Hz
100%
5400 W
