3. Introduction – Plus III-6KLRB/ Plus III-10KLRB
3.1 Product Specification and Performance
1) General Specification
INPUT
Model No.
Plus III-6KLRB
PlusIII-10KLRB
Phase
Single
Voltage
176~276VAC
Frequency
(45~55)/(54~66) Hz
Current(A)*
25.8
43.0
THDI
< 5% @ full load
Power Factor
≥0.99 @ full load
*Rated current while input rated voltage is 230VAC
OUTPUT
Model No.
Plus III-
6KLRB
PlusIII-
10KLRB
Power
rating
6kVA/5.4k
W
10kVA/9k
W
Voltage
208*/220/230/240×（1 士 1%）VAC
Frequency
50/60×（1±0.05）Hz (Battery mode)
Wave form
Sinusoidal
Load type
PF 0.5 1, lagging
THDV
< 2% @ full linear load
<5% @ full non linear
load
Overload
In Line mode**:
10 min 105~125%
1 min 125~150%
10 s >150%
100 ms >170%
In Battery mode:
2 min 105~125%
30 s 125~150%
100 ms >150%
*The load capacity would be derated to 90% automatically when the output voltage is
