STAINLESS UV - DIRECT
160mm
195mm
FD
22mm HOT
DRAW - OFF
“
F PTRV BOSS
22mm SECONDARY
RETURN (not always tted.
See table)
22mm COLD FEED WITH
DIP PIPE TO DEFLECTOR
IN BOTTOM OF CYLINDER
1
2
SECOND IMMERSION
HEATER (not always tted.
See table)
15.0
0
25.0
0
30.0
0
45.0
0
CODE HEIGHT DIAMETER D F ERP BAND LOAD PROFILE kWH/Annum
ED90 718 550 N/F N/F D M 1451
ED120 906 550 N/F 510 D M 1475
ED150 1093 550 N/F 610 D L 2779
ED180 1281 550 N/F 710 D L 2796
ED210 1469 550 1000 810 D L 2844
ED250 1719 550 1250 950 D L 2889
ED300 2032 550 1500 1100 D XL 4560
11
STAINLESS UV
UNVENTED HOT WATER CYLINDERS
