TECHNICAL SPECIFICATIONS
STAINLESS UV -
SOLAR INDIRECT
All Dimensions are in mm and
are of the cased unit.
N/F = not fitted.
25.0
0
15.0
0
40.0
0
45.0
0
35.0
0
DRY STAT
POCKET
DRY STAT
POCKET
22mm COLD
FEED WITH DIP PIPE
TO DEFLECTOR IN
BOTTOM OF CYLINDER
22mm SECONDARY RETURN
(not always tted. See table)
½” F PTRV BOSS
22mm HOT DRAW-OFF
EF D C B A G H
50.0
0
0
45.0
CODE HEIGHT DIAMETER A B C D E F G H ERP BAND STANDING LOSS (W)
ET150 1093 550 290 345 642 697 N/F 892 390 693 B 54
ET180 1281 550 290 345 674 729 N/F 1080 390 725 B 58
ET210 1469 550 365 420 779 834 1150 1268 465 830 C 70
ET250 1719 550 365 420 950 1005 1400 1518 465 1000 C 81
ET300 2032 550 365 420 979 1034 1600 1832 465 1030 C 92
13
STAINLESS UV
UNVENTED HOT WATER CYLINDERS
