Apple ADC - Chassis Removal

Apple Cinema Display 22" (ADC) Take Apart - 17
Chassis
Chassis
Tools
This procedure requires the following tools:
• #2 Phillips screwdriver
Part Location
Preliminary Steps
Before you begin, do the following:
• Place the display face down on an ESD mat
• Remove the foot assembly and hinge cover
• Remove the rear cover
• Remove the hinge
• Remove the main board and shield
• Remove the ADC cable and shield
• Remove the USB cable
• Remove the front bezel.
