Apple Cinema Display (20-inch)
922-5551 2.0 mm Hex, 8.8 mm (L) Foot to Hinge(3)
922-5602 2.5 mm Hex, 22 mm (L) Rear Cover - bottom (3)
922-5601 2.5 mm Hex, 15.4 mm (L) Rear Cover - top & sides (9)
922-5619 #2 Phillips, 19.8 mm Chassis corners (4)
922-5618 #2 Phillips (flat-head), 6.2 mm Chassis to panel - top side (2)
922-5560 #2 Phillips (round-head), 5.8 mm Chassis to panel - bottom side (2)
#2 Phillips, 5 mm EMI shield to chassis (10)
922-5554 #2 Phillips, 8.2 mm Inverter board (4), main board (4),
ADC cable hold down block and cable clamps (4),
USB socket and cable clamps (4)
922-5620 #2 Phillips, 8.4 mm Hinge to chassis (4)
922-5617 #2 Phillips, 10.7 mm Inner bezel to chassis (12)
922-5749 Cable clamp ADC main cable (1)
922-5553 #2 Phillips, 7.7 mm Touch switch boards (2)
922-5748 Cable clamp Power switch cable (1)
922-5750 Cable clamp USB cable (2)
922-5792 Cable clamp ADC cable to panel (1)
Screw and Cable Clamp Matrix
