44 - Cinema HD Display (23-inch DVI) Take Apart
Bottom Stabilizer Bar
3. While supporting the bar so it does not bend, free the left end Install the replacement
bottom stabilizer bar from the adhesive at that end.
Note: Carefully rub off any remnants of adhesive. It does not have to be reapplied
when reassembling the display.
4. Install the replacement bottom stabilizer bar, and reassemble and test the display.
