83 - iBook G4 (12-inch Mid 2005) Take Apart
Modem
Procedure
1. Warning: When removing the modem, be careful not to strain the modem cable
or shield. Read all of the procedure before removing and replacing the modem.
2. Peel up any strips of tape, if present, from the modem board.
3. Remove the following screws:
• two identical 3.5-mm long screws from the modem board
• one screw from the small shield
4. Remove the small shield from the computer assembly.
