iBook (14.1 LCD 16 VRAM) Take Apart - 86
Antenna Board
Procedure
Note: Although your bezel assembly might appear somewhat different than shown, the
steps to follow are the same.
1. With the bezel assembly lying on a soft cloth, peel up the tape from the antenna
board.
2. Note the placement of the antenna board and the routing of the cables that are
soldered to and run along the bottom of the antenna board.
