10. Touch a metal surface on the inside of the computer to discharge any static electricity, as shown (Figure 5).
Important : To avoid electrostatic discharge damage, always ground yourself by touching the computer’s framework before
you touch any parts or install any components inside the computer. To avoid static electricity building back up in your body,
do not walk around the room until you have completed the installation and closed the computer.
Removing the Installed AirPort Card
1. Unlatch the flexible wire holder that secures the card (Figure 6).
2. Use the pull-tab on the card to remove it from the slot.
3. Disconnect the antenna cable from the AirPort Card by pulling straight back on its connector.
3iBook (Dual USB - Late 2001 - 14.1 LCD - 16 VRAM - 14.1 LCD 16 VRAM) - AirPort Card
Figure 5
Figure 6
