iBook (14.1 LCD 16 VRAM) Take Apart - 34
Top Case
12. Reassemble and test the computer.
Note: When reinstalling the RAM shield, insert the edge next to the trackpad cable
first. Then make sure the RAM shield lays flat and the two screw holes align with the
two holes in the heat spreader before installing the screws.
