Apple iPod mini - Page 18

Testing Procedures - 17
iPod mini
BATT A2D
1. Skip this test.
A2D STAT (A2D Status test)
1. The screen will show:
• ID (ID of the main board)
• VCC (Power)
• BATT (Battery)
• ACC (Accessory ID)
2. Pass condition:
• ID = 74
• CHGR = 0
• ACC = 255
3. Press Play to return to the diagnostics menu (you may need to press Play several
times to exit the test).
FIREWIRE
1. Make sure the iPod is connected to the computer with the FireWire cable.
2. The screen will show:
3. The Pass condition is FW PASS.
A2D TEST
ID 74
VCC 345
BATT392
TEMP 0
CHGR 0
ACC 255
FW TEST
CONNECT
SPD S400
CHIP OK
FW PASS
