LED Cinema Display (24-inch) — Updates 7
2010-02-08
Updates
Updated 8 February 2010
Troubleshooting: General: Test Points Diagram, added TP61•
Troubleshooting: Symptom Charts: “Dead Unit / No Power”:•
Step 5: changed “Yes” Action to lead to Blank/No Video, • Step 3;
Step 8, corrected voltage for TP11 to 24.5VDC (was incorrectly noted as 15VDC); •
Step 9, corrected “TP11” to “TP13”.•
Troubleshooting: Symptom Charts: “Camera Issues”: added link to • kBase #HT3957: “About
the LED Cinema Display iSight Camera Firmware Update 1.0”.
Updated 28 October 2009
Added new section: About This Manual•
Basics: replaced Technical Specications (p. 9) with a link to AppleCare Tech Specs•
Troubleshooting: General: updated Troubleshooting Theory section•
Troubleshooting: Symptom Charts: corrected hyperlink at top of p. 17•
Take Apart: General: replaced ESD section with hyperlinks to current ESD articles & training; •
added section for handling and removing a broken glass panel
Take Apart: Stand: added image showing removal of rear housing from stand; added note •
about VESA Mount procedure
Added new sections: Additional Procedures: VESA Mount and Retrieving Mechanism•
Updated 2 December 2008
