HOWEVER, THIS SET CAN BE ADJUSTED TO SPECIFIC NEEDS ACCORDING
TO VEHICLE USE.
WHEN COUNTING THE NUMBER OF CLICKS OF THE ADJUSTER SCREW (1),
ALWAYS START FROM THE STIFFEST SETTING (ADJUSTER SCREW FULLY
CLOCKWISE).
TO AVOID DAMAGE, DO NOT FORCE THE ADJUSTER SCREWS (1) BEYOND
THE RESPECTIVE END OF TRAVEL ON EITHER SIDE.
03_05
•
Turn the (1) screw to adjust the shock absorber hydraulic rebound damping.
ADJUST SHOCK ABSORBER REBOUND DAMPING TO SUIT THE VEHICLE OP-
ERATING CONDITIONS.
THE STANDARD SPRING PRELOAD SETTING IS SUITABLE FOR THE MAJOR-
ITY OF RIDING CONDITIONS. IF REQUIRED, CONTACT AN OFFICIAL Aprilia
DEALER TO REQUEST A PERSONALISED SETTING.
63
