23
use and maintenance RS 125
AUXILIARY EQUIPMENT
GLOVE/TOOL KIT COMPARTMENT
The glove/tool kit compartment is
positioned under the rider saddle; to reach
it:
u
Position the vehicle on the stand.
u
Remove the rider saddle, see page 56
(REMOVING THE RIDER SADDLE).
u
Remove the plastic panel.
The tool kit (4) includes:
– 3, 5 mm Allen spanners
– 10-13 mm double fork spanner
– 8-mm fork spanner
– 17-21 mm spark plug socket spanner
– Double-ended, cross-/4 mm hexagon
spanner-headed screwdriver.
– Special socket wrench to adjust clutch
play.
– Tool case
Max. allowed weight: 1.5 kg
4
RS_125_UK.book Page 23 Tuesday, June 13, 2006 1:34 PM
