TABLE C - LAMBDA PROBE PASSAGE
•
Both wiring (1) of the lambda sensors
must pass through the cable grommet
(2) connected to the secondary air pipe
(3).
TABLE D - HEAD ZONE PASSAGES
1) Coil connectors (must be attached to the can-
ister support).
2) Purge valve (check the correct connection of the
connector).
3) Injector connectors (the wiring must pass under
the canister pipe).
TABLE E - FILTER BOX ZONE PASSAGES
•
Check the correct insertion of the in-
take air temperature sensor connector.
Electrical system RS 660 - Tuono 660
ELE SYS - 116
