THE FOLLOWING OPERATIONS REFER TO A SINGLE STEM BUT APPLY TO BOTH.
•
Undo both locking screws of the lock
clamp placed on the brake pipe on left
stem protection.
•
Release the brake pipe from the left stem protection.
•
Undo both stem protection fixing
screws.
•
Remove the stem protection.
•
Remove the front wheel.
•
Loosen the screw on the upper plate.
•
Loosen both lower plate screws.
RX SX 125 Suspensions
SUSP - 147

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA SX 125 and is the answer not in the manual?

APRILIA SX 125 Specifications

General IconGeneral
Displacement124.2 cc
Cooling SystemLiquid cooled
Fuel SystemElectronic fuel injection
Transmission6-speed
Rear SuspensionMonoshock
Front Tire100/80-17
Rear Tire130/70-17
Compression Ratio12.5:1
StarterElectric
ClutchWet multi-plate
Front Brake Disc300 mm
Rear Brake Disc220 mm
Dry Weight134 kg
Bore x Stroke58 mm x 47 mm
Max Power11 kW (15 HP) @ 10, 000 rpm
Front Suspension41 mm USD fork
Front BrakeSingle 300 mm disc
Rear BrakeSingle disc
Fuel Tank Capacity7 liters
FrameSteel perimeter
Engine TypeSingle-cylinder, 4-stroke
