5. Battery Charging
Three ways to charge:
5.1 Charging mode 1: Hang main unit (NO.1) to wall mount (NO.2). Plug the charger output end in
the battery and connect input end to main socket. The charge indicator (NO.3) shows 100% power
when fully charged. See Figure 5-1. Charging time is 4 to 6 hours.
5.2 Charging mode 2: Plug the charger output end in the battery and connect input end to main
socket. The charge indicator (NO.3) shows 100% power when fully charged. See Figure 5-2.
Charging time is 4 to 6 hours.
5.3 Charging Mode 3: Release the latch (NO.4) to remove the battery pack from main unit and place
it on a solid surface. See Figure 5-3. LED will flash white light (NO.5) when charging and flash green
light when fully charged. Charging time is 4 to 6 hours.
Attention: The machine is unable to start when charging.
