APT LW39-16B - Page 2

LW39-16B
42017.1
Siemens Electrical Apparatus Ltd., Suzhou, Tiantai Branch
Installation
L: The size of the switch body
t : The thickness of the mounting plate
n: The stage of the switch
LW39-16B
LW39-16BP
LW39-16B-□...□-48
LW39-16BP-□...□-48
LW39-16BYM(LW39-16BPYM)
30±1
L=(39.7+10 x n )±2
t=1~3
49±0.5
49±0.5
36±0.2
36±0.2
4-Ø4.5
Ø10
30±1
L=(22.2+10 x n )±2
t=1~3
49±0.5
49±0.5
36±0.2
36±0.2
4-Ø4.5
Ø10
Self-reset=L+18
Instillation position
49±0.5
30±1
L=(22.2+10 x n )±2
t=1~3
36±0.2
36±0.2
64±0.5
4-Ø4.5
Ø10
Self-reset=L+18
30±1
L=(24.7+10 x n )±2
t=1~3
64±0.5
64±0.5
48±0.2
48±0.2
4-Ø4.5
Ø10
Self-reset=L+18
Instillation position
Instillation position
30±1
48±0.2
48±0.2
L=(24.7+10 x n )±2
t=1~3
64±0.5
78±0.5
Ø10
4-Ø4.5
Instillation position
Self-reset=L+18
Ø10
4-Ø4.5
Ø34
37±1
L=(50.7+12 x n)±2
t=1~3
(124.3)
(113.8)
(45.8)
3248
100
110.5
48±0.2
48±0.2
48±0.2
Instillation position
Self-reset=L+12
LW39-16BZL
LW39-16BS
LW39-16BM
LW39-16BNZ
LW39-16BNZD
LW39-16BSNZ
Self-reset=L
Instillation position
49±0.5
49±0.5
30±1
L=(35.7+10 x n )±2
t=1~3
30±0.2
2-Ø4.5
Ø10
Self-reset=L
Instillation position
33±1
L=(22.2+10 x n )±2
72±0.5
76±0.5
60±0.2
64±0.2
52.2
+0.4
0
64.2
+0.4
0
4-M3
47±0.5
30±1
L=(26.7+10 x n )±2
49±0.5
49±0.5
36±0.2
36±0.2
mounting patch
A
A Side
4-M4
Self-reset=L+18
Instillation position
Self-reset=L+18
Instillation position
72±0.5
76±0.5
60±0.2
64±0.2
52.2
+0.4
0
64.2
+0.4
0
lights
4xM3
47±0.5
B
L=(40.2+10 x n )±2
A P T
A
Compatibility
LW39-16BNZD
LW39-16BNZY
LW39-16BNZDY
/
Dimension A
27±1
Dimension B
31.5±1
33.5±1
27±1 33.5±1
1
2
No.
3
Self-reset=L
Instillation position
31.5±1
L=(35.7+10 x n )±2
t=1~3
30±0.2
Ø10
2xØ4.5
49±0.5
49±0.5
Self-reset=L
Instillation position
