Duct Adapter
Adapter Feet
12
Ⅱ: Take out the duct adapter and adjustable rubber feet from the
machine body
1. Unscrew the 2 screws under the lower cover, and remove the lower front panel.
2. Use a screwdriver to remove the 2 screws on the top cover and remove the top front panel.
3. Take out the duct adapter and adjustable rubber feet from the machine body.
4. After the accessories are taken out, install the top front panel and lower front panel.
Remove the top cover screws
Remove the lower cover screws
