Aqua Select 832402B - Antigua Step Parts Assembly Diagram; Numbered Parts and Quantities

PART # MODEL # DESCRIPTION QTY
1
832402SR
Steprail 2
2 AC LONGPOS Long Post 2
3
832402BS
Steps 4
4
832402MB
Mounting Bracket 2
5 AC RISER Step Raisers 4
6 AC SHORTPOS Short Post 2
7
832402LC
Lock Caps 16
8 AC PANELS Side Panels 2
9 AC BASE Step Base 2
4
ANTIGUA STEP PARTS
1
2
3
4
5
6
7
8
9
