3
STEP 1
• Lay gate (AC GATE) flat on a clean,
level area and open plastic hinges as
shown.
•
Locate hinge post (AC HINGEPT) and lay next to gate with
openings lined up to plastic hinges of gate.
• Stick plastic hinges of gate through openings of hinge post.
The wider part of the hinge post is the bottom and should be
lined up with the bottom of the gate (flat part indicates
bottom).
• Wrap plastic hinges around hinge
post and secure in place using
(8) of the #7 x 1/2” screws from
hardware (AC HDW30988).
The Ladder must be installed based on Manufacturer’s Instructions
• One person on the Ladder/Stair at a time
• This Ladder is designed and manufactured for a specific Pool Wall Height
and/or Deck of the Pool
• For Entry/Exit of pool, face the ladder at all times
• Remove and secure Ladder when pool is not occupied
• The Ladder will be suitable up to 54” Maximum Pool Height
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ PRIOR TO ASSEMBLY/USE
