5
SPECIFICATIONS
Models Covered WF101, WF321, WF326, WF541, WF546, WT540/1P & WT540/1G
Colours P = Polar, G = Graphite, A = Aluminium
Dimensions Height 850 mm Width 595 mm
Depth 600 mm Weight 66 kg. Packed approximately 69 kg
Country of Origin Great Britain
Electrical Supply 220/240 Volts AC @ 50Hz Fuse 13 amp
Energy Energy Class: A+ @ 6 kg
Washing Performance Class: A+
Spin Efficiency Class: B
Energy Consumption 1.02 kWh / Cycle @ 60°C Cotton
Water Consumption 55 litres @ 60°C Cotton
Wash Load 6 kg Cottons
Spin Speed WF101 1000 rpm WF321 1200 rpm WF326 1200 rpm
WF541 1400 rpm WF546 1400 rpm WT540/1P 1400 rpm
WT540/1G 1400 rpm
Control PCB 220/240 Volt 50/60Hz Type Merloni EVO 2
Water Supply Cold Valve - Coil Resistance 3.8 KΩ
Max Pressure = 1 Mpa (10bar)
Minimum Pressure = 0.05 Mpa (0.5bar)
Wash Heater 1800 Watts @ 230 volts
Resistance 30 Ω approximately
Thermistor NTC Resistance: 20 KΩ @ 20°C
Motor Universal Series Wound 230V 50Hz AC with tapped field
Pump 2 Pole Synchronous
220 / 240 Volt, Resistance = 162 Ω
Door Lock P.T.C. Bimetallic - Time Delay approximately 2 minutes
Torque Settings Upper Balance Weight = 24 Nm
Lower Balance Weight = 24 Nm
Pins Resistances FHP/ACC
1-2 Armature Varies with brush-gear 4.8 Ω ± 8%
3-5 Full Field 1.6 Ω ± 8%
3-4 Tapped Field 0.8 Ω ± 10%
6-7 Tacho 16 Pole (8 pairs) 136 Ω ± 10%
