AquaSource FP4A4057CP - Installation With Deck Plate

5
ASSEMBLY INSTRUCTIONS
5. Slide rubber washer (E) and metal washer
(F) onto shank of faucet body (D). Secure
faucet body (D) to sink with lock nut (G) and
preassembled screws.
1
2
3
5
G
D
E
F
4. Unscrew preassembled screws on lock nut
(G)untiltheyareushwiththefaceofthe
lock nut (G).
3b. With deck plate installation: Place a bead of
clear silicone sealant (not included) around
the base of the putty plate (C). Place putty
plate (C) and deck plate (B) on sink (not
included). Insert faucet body (D) through
deck plate (B).
4
G
1
2
2
3b
D
B
C
ASSEMBLY INSTRUCTIONS
