PART DESCRIPTION QUANTITY
A Spray Head (preassembled) 1
B Deck Plate 1
C Putty Plate 1
D Faucet Body 1
E Rubber Washer (preassembled) 1
F Metal Washer (preassembled) 1
G Lock Nut (preassembled) 1
H Water Supply Line (preassembled) 2
I Hose (preassembled) 1
J Quick Connector (preassembled) 1
K Weight 1
L Discharge Tube 1
HARDWARE CONTENTS (shown actual size)
PACKAGE CONTENTS
AA
Allen Wrench
x 1
