Araknis Networks AN-310-RT-4L2W Quick Start Guide

7
310 Series Single-WAN Gigabit VPN Router
Quick Start Guide
© 2018 Araknis Networks®
Step 2: Install
Rack Mount Wall Mount (310 only) Shelf Mount
A
B
C
WAN
LAN
WANLAN
WANLAN
WANLAN
NOTES: For Rack Mount, the router can be mounted in an EIA standard size 19-inch rack or chassis, which can be placed in a wiring closet
with other equipment. To install, attach the mounting brackets to the router’s side panels (one on each side) and secure them with the
screws provided (please note that these brackets are not designed for palm size routers). Do not stack other equipment on top of the router
to avoid possible interference or damage. The 310 routers both have the same center-mounting rack ears included. The products can be
mounted onto thick plywood or concrete walls.

Araknis Networks AN-310-RT-4L2W Specifications

General

Brand	Araknis Networks
Model	AN-310-RT-4L2W
Category	Network Router
Language	English
