ARB CKMP12 - Detailed Specifications; General Specifications; No Load & Tyre Pressure Specs; External Connections

ARB AIR COMPRESSOR
Service and Parts Manual
Revision Date 21/12/17
3.5
CKMP12
Air Compressor – Detailed Specifications
GENERAL SPECS
METRIC
IMPERIAL
SUPPLY VOLTAGE
12
Volts DC
12
Volts DC
MAX CURRENT DRAW
32
Amps @ 690 KPa
32
Amps @ 100 PSI
FUSE RATING (Maxi-Blade type)
40
Amps
40
Amps
RELAY RATING
40
Amps
40
Amps
WEIGHT (total kit)
6.5
Kgs
14.3
Lbs
DIMENSIONS -LENGTH
440
mm
17.32
inches
-WIDTH
238
mm
9.37
inches
-HEIGHT
208
mm
8.19
inches
DUTY CYCLE @ 22°C [72°F]
50
%
30
mins. per hour
PRESSURE SWITCH CLOSED
< 520
KPa
< 75
PSI
PRESSURE SWITCH OPEN
> 725
KPa
> 105
PSI
SAFETY VALVE PRESSURE
> 1035
KPa
> 150
PSI
MOTOR THERMAL CUT-OUT
115
degrees C
239
degrees F
MAX. AMBIENT TEMPERATURE
100
degrees C
212
degrees F
NO LOAD SPECS
METRIC @ 0 KPa
IMPERIAL @ 0 PSI
CURRENT DRAW
13
Amps
13
Amps
AIR FLOW RATE
75.1
L/min.
2.65
CFM
SPECS @ TYRE PRESSURE
METRIC @ 200 KPa
IMPERIAL @ 29 PSI
CURRENT DRAW
22.9
Amps
22.9
Amps
AIR FLOW RATE
61.6
L/min.
2.18
CFM
EXTERNAL CONNECTIONS SPECS
AIR INTAKE THREAD (female)
1/4-18 NPSC (parallel pipe thread)
AIR FILTER THREAD (male)
1/4-18 NPT (tapered pipe thread)
PRESSURE SWITCH THREAD
1/4-18 NPT (tapered pipe thread)
SAFETY VALVE PORT THREAD
1/8 BSPP (parallel pipe thread)
MANIFOLD PORT THREAD
1/4-18 NPT (tapered pipe thread)
AIR COUPLING FITTING TYPE
‘US Industrial Standard’
(international equivalent standards)
ISO 6150 B
Rectus series 23/24/1400
Tema series 1400
Legris series 23
DYNAQUIP D3
CEJN 310
US.MIL.C 4109
Norma / AFNOR: NF.E49.053
Parker series 30-¼” and 20-¼”
Aignep 220
Hansen series 3000
Norgren series 237
Gromelle series 600
WARRANTY
This ARB Air Compressor is designed to provide many years of trouble free recreational use, and is warranted
to be free from manufacturing defects for two (2) years from the date of purchase.
NOTE : The specifications above were recorded under laboratory conditions @ 22°C [72°F].
