JACK Instruction Manual / 11
Original Instruction
How to use your JACK
RAISING THE JACK
1. VEHICLE SAFETY
Stabilise the vehicle by applying chocks to the wheels
at the opposite end of the vehicle being lited.
*See safety information section 14
2. CLAMP LOCK
To position the hook for liting, release the lever on
the side of the clamp. The quick release lever does
not need any adjustment; pull the lever away from
the body of the Jack to release the clamp. If the
clamp no longer applies enough clamping force;
close the lever and adjust with a hex key until the
hook is adequately clamped. Do not over tighten.
If greater clamping force is required; With the
clamp lock in the closed position, use a 5mm
Hex Key to tighten the clamp bolt. Do not exceed
4.Nm.
