ARB Jack - Page 24

24 / JACK Instruction Manual 3789833-20200901
Original Instruction
3. DESCENT CONTROL
The initial two-thirds of the release lever travel is intended for slow lowering
of the loaded Jack. The final third of the lever travel is for fast lowering of the
unloaded Jack. Do not use the fast lowering speed while the Jack is loaded.
1 2 3
1. CLOSED 2. SLOW 3. FAST
