7
DC Current Operating Procedure
CAUTION: Prior to making any connections, place the PMC in Standby Mode.
Connect the Model 918B to the PMC as shown below and perform the following steps:
1. Press DC.
2. Press CURRENT.
3. Enter the desired current using the keypad and the units key.
4. Press OPER.
5. MODIFY, MEMORY, or % DEV may be used.
6. To remove the output signal, press STBY when the measurement is complete.
