ARC Audio IDX - XEQ Technical Specifications

XEQ
Optional
2-WAY With FADING FRONT and REAR
7
XEQ
Signal to Noise Ratio (A-Weighted)
>100dB
THD @ 8.0V Output
0.005%
Channel Separation
>75dB
Sub Woofer Crossover
45Hz-150Hz 12dB/Octave
Input Impedance
15K Ohms
RMS Output @ 1KHz
9.0 Volts
Frequency Response
20Hz-30KHz
EQ Frequency Range @ 50Hz
100Hz
275Hz
770Hz
2.2KHZ
6.0KHz
16.8KHZ
+/- 12dB, Q=1.38
+/- 12dB, Q=1.20
+/- 12dB, Q=1.25
+/- 12dB, Q=1.18
+/- 12dB, Q=1.08
+/- 12dB, Q=1.10
+/- 12dB, Q=0.98
XEQ SPECIFICATIONS
XEQ IDX
XEQ
8
