MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION IV - SYSTEM FUNCTIONS
4.8 SET-UP FUNCTIONS
3. HEAD-CAL - Provides a method for calibrating a M-9 weld head to the
power supply.
4. REV
- Used to display the SOFTWARE REVISION of an M-207A.
Depending on intended use, M-207A’s may have different software revisions.
5. PRINT EMM - Used to print a copy of the EMM memory.
6. ARC V FLT - Used to de-activate STUB OUT and HIGH VOLT faults.
These faults are usually needed to be turned off for manual welding, see
section 7.4.7.
7. AMP - TIME - Used to change the least significant digit of Level Current or
Level Time from whole numbers or tenths (000 or 000.0).
8. SENSORS - Used to activate and define external fault inputs.
9. QTY-RESET - Used to reset the quantity count for each weld schedule or
for the entire library.
10. START LEVEL - Used to set the value of INITIAL current used at arc
start.
11. DATE RESET
- Used to reset DATE.
12. CANNED PROG - Used to LOCK or UNLOCK PROGRAM MODE for
canned programs in positions 71 to 100.
13. PRINTER - Used to select AUTO or MANUAL print mode.
14. WELD DATA RECORDING - Used to activate both entry of WELD ID#
before sequence and to activate recording weld information into a memory
card after each sequence.
15. OPERATOR ID/NAME - Used to enter the ID number or name of the
weld operator.
16. SERIAL NUMBER - Used to enter the M-207A Serial Number for Weld
Data Record feature.
4.14
